SVT XXAWG-HAOKING ELECTRONIC LIMITED

SVT XXAWG

Details

			Rating: 60℃ / 105℃ 300V Application: Power Supply Cord for Vacuum Cleaners, Printers Standard: UL62 / C22.2 No. 49
No. of Conductor	Conductor			Insulation		Jacket
	AWG Size	Sectional Area (mm2)	Construction (No./mm)	Nom. Thick. (mm)	Nom. Diam. (mm)	Nom. Thick (mm)	Nom. Diam. (mm)
2	18	0.824	41 / 0.160	0.38	2.15	0.76	6.05
2	17	1.030	52 / 0.160	0.38	2.30	0.76	6.35
2	16	1.300	26 / 0.253	0.38	2.45	0.76	6.65
3	18	0.824	41/0.160	0.38	2.15	0.76	6.35
3	17	1.030	52/0.160	0.38	2.30	0.76	6.70
3	16	1.310	26/0.253	0.38	2.45	0.76	7.00

Marking:(UL) /C(UL) E495753 SVT 3/C xxAWG(xxmm²)300V 105℃ FT1 YAOFENG
