UL SJT XXAWGx4C

Details

Rating:

60℃ / 105℃, 300V
-40℃~ 60℃, 300V (For SJTW)

Application:
Power Supply Cord for Electrical Appliances

Standard: UL 62 / C22.2 No.49

No. of Conductor	Conductor			Insulation		Jacket
	AWG Size	Sectional Area (mm2)	Construction (No./mm)	Nom. Thick. (mm)	Nom. Diam. (mm)	Nom. Thick (mm)	Nom. Diam. (mm)
2	18	0.824	41 / 0.160	0.76	2.80	0.76	7.35
2	16	1.310	26 / 0.253	0.76	3.10	0.76	7.95
2	14	2.080	41 / 0.253	0.76	3.50	0.76	8.70
2	12	3.310	65 / 0.253	0.76	4.00	1.14	10.50
2	10	5.260	104 / 0.253	1.14	5.40	1.52	14.10
3	18	0.824	41 / 0.160	0.76	2.80	0.76	7.80
3	16	1.310	26 / 0.253	0.76	3.10	0.76	8.40
3	14	2.080	41 / 0.253	0.76	3.50	0.76	9.30
3	12	3.310	65 / 0.253	0.76	4.00	1.14	11.00
3	10	5.260	104 / 0.253	1.14	5.40	1.52	14.80
4	18	0.824	41 / 0.253	0.76	2.80	0.76	8.60
4	16	1.310	26 / 0.253	0.76	3.10	0.76	9.20
4	14	2.080	41 / 0.253	0.76	3.50	0.76	10.30
4	12	3.310	65 / 0.253	0.76	4.00	1.14	12.10
4	10	5.260	104 / 0.253	1.14	5.40	1.52	16.40

Marking:(UL)/C(UL) E495753 SJT3/C xx AWG(xxmm²)300V 105℃ FT1 YAOFENG
Remarks:1.W Marked for outdoor use
